Toulon port map
| anchorage information | |
|---|---|
| secure anchorage(s) position | Grande Rade ou Petite Rade |
| min depth of anchorage | Grande Rade = 25 m / Petite Rade = 12 m |
| type of bottom | Grande Rade: Sand / Petite Rade: Mud |
| wind current | WNW / ENE |
| General slope of bottom | Flat |
| distance to tender landing dock | Grande Rade = about 1500 m / Petite Rade = 1000 m |
| minimum depth of channel of fairway to tender dock | - |
| minimum depth of water at tender dock | - |
| Prevailing weather | Main winds: West North Westly & East South Eastly |
| Location of pilots boarding area | 43°05,12' N - 005°57,45' E |
| Approach chanel width & depth | No limit |
| Distance from pilot station to dock/anchorage | 4 NM |
| Estimated time from pilot station to dock/anchorage at max.speed allowes by port authority | About 40 min. Max. speed = 12 knots |
| Port established max. LOA | Toulon City Center = 300 m / Mole La Seyne = 340 m |
| Port established max. Draft | Toulon City Center = 9.5 m / Mole La Seyne = 9 m |
| Depth & diameter of turning basin | Depth = 12 m / Diameter = 700 m |
| Air draft restrictions | No restriction |
| Tides & currents | Tide = 0.50 m / Currents = None |
| Name/draft/LOA of largest ship called in the port | Toulon City Center: Brillance of the Seas (LOA=249 m / draft=8 m) Mole La Seyne (Marepolis): Splendida ( LOA=333 m /draft=8.7 m) |
| distance to tender landing dock from anchorage | Grande Rade = about 1500 m / Petite Rade = 1000 m |
| general information | |
|---|---|
| Terminal/Restrooms in pier area | Yes |
| Shuttle bus | No from Toulon City center pier, Yes from La Seyne Cruise Terminal |
| Parking place for buses | Yes |
| Taxi | Yes |
| Rental cars | Yes |
| Public transportation | Yes |
| Shopping | Yes |
| Local currency | € |
| ATM | Yes |
| Tax refund | No |
| Public telephones in pier area | Yes |
| Internet access in pier area | Yes |
| Mailboxes in pier area | No |
| Distances - airport | 30 km |
| Distance to city centre | 500 meters |
| Nearest hospital | 1 km |
| Port Services / Facilities & Information | |
|---|---|
| Bunkers delivery /method | Yes |
| Grey water | Yes |
| Waste handling | Yes |
| Waste water method | Sewage by truck |
| Anchorage | Possible for a 3rd ship when all piers are occupied |
| Pontoons | No |
| Emergency | Channel 9 |
| Medical emergency | 112 |
| Tidal movement | No |
| ISPS approved | Yes |
| Designated quays for cruise ships | Yes, 4 piers |
| Beam | No limitation |
| WiFi | Yes |
| Max size ship in port | No limitation |
| Max number of passengers per day in port | No limitation |
| Max number of ships per day in port | 4 + option for 1 at anchor |
| Ship’s stay min /max | 08h30-18h00 in Toulon City center, No limitation in La Seyne Cruise Terminal |
| Environmental limitations /restrictions | None |
| Maximum ship length | 290 meters in Toulon City center, 340 meters in La Seyne Cruise Terminal |
| Maximum ship draft and depth in sea | Toulon 8.2 - La Seyne 9.0 |
| Maximum ship airdraft if bridge | No limitation |
